Linux Monitor Zenpack

This ZenPack monitors the Linux Operating System.

Background

This ZenPack provided monitoring support for Linux, leveraging OpenSSH for data access. In addition to system health, disks, LVM, services, and processes are monitored.

Features

  • Monitors multiple Linux flavors and versions
  • OpenStack LVM volume integration
  • Monitors LVM Physical Volumes, Volume Groups, and Logical Volumes
  • Block Device monitoring
  • Service Monitoring via Sysvinit, Systemd, Upstart
  • Root Cause Analysis with Impact Support
  • Dynamic View support

Note

This version of LinuxMonitor fully replaces EnterpriseLinux. To avoid related errors in zenhub logs, EnterpriseLinux ZP should be removed after the new LinuxMonitor has been applied.

Discovery

The following entities will be automatically discovered. The attributes and collections will be updated on Zenoss normal remodeling interval which defaults to every 12 hours.

Hard Disks
Attributes: Name, Size, LVM PV

Note

  • On CentOS5, RHEL5 (and possibly others), the lsblk command is not available, in which case this component will be missing.
  • To ignore unmounted drives, set the zIgnoreUnmounted configuration property to True.
Processors
Attributes: Socket, Manufacturer, Model, Speed, Ext Speed, L1, L2, Voltage
IP Services
Attributes: Name, Protocol, Port, IPs, Description
File Systems
Attributes: Mount Point, Storage Device, Total Bytes, Used Bytes, Free Bytes, % Util
Interfaces
Attributes: IP Interface, IP Addresses, Description, MAC Address, Operational Status, Admin Status
Network Routes
Attributes: Destination, Next Hop, Interface, Protocol, Type
Snapshot Volumes
Attributes: Name, Volume Group, Logical Volume, Size, Block Device, File System, Active Relations: Logical Volumes
Physical Volumes
Attributes: Name, Format, Size, Free, % Util, Block Device, Volume Group Relations: Volume Groups
Volume Groups
Attributes: Name, Size, Free, % Util, Snapshot Volumes, Logical Volumes, Physical Volumes
Logical Volumes
Attributes: Name, Volume Group, Size, Block Device, File System, Active, Snapshot Volumes Relations: Volume Groups
OS Processes
Attributes: Process Class, Process Set, Restart Alert?, Fail Severity
OS Services
Attributes: Name, Loaded Status, Active Status, Main PID, Processes, Description

Note

On some Linux flavors some fields (Loaded Status, Processes, Description) could be empty.

Set Linux Server Monitoring Credentials

All Linux servers must have a device entry in an organizer below the /Devices/Server/SSH/Linux device class.

Tip

The SSH monitoring feature will attempt to use key-based authentication before using a configuration properties password value.

  1. Select Infrastructure from the navigation bar.
  2. Click the device name in the device list. The device overview page appears.
  3. Select Configuration Properties from the left panel.
  4. Verify the credentials for the service account. The zCommandUsername property must be set. To use public key authentication you must verify that the public portion of the key referenced in zKeyPath is installed in the ~/.ssh/authorized\_keys file for the appropriate user on the linux server. If this key has a passphrase you should set it in the zCommandPassword property. If you'd rather use password authentication than setup keys, simply put the user's password in the zCommandPassword property.

Using a Root User

This ZenPack requires the ability to run the pvs, vgs, lvs, systemctl, initctl and service commands, remotely on your linux server(s) using SSH. By default, these commands are only allowed to be run locally. To remotely run these commands, the root user must not be required to use TTY.

  1. Install the sudo package on your server.

  2. Allow root user to execute commands via ssh without a TTY.

    1. Edit the /etc/sudoers file.

    2. Find the line containing root ALL=(ALL) ALL.

    3. Add this line underneath it:

      Defaults:root !requiretty

    4. Save the changes and exit.

Using a Non-Root User

This ZenPack requires the ability to run the pvs, vgs, lvs, systemctl, initctl and service commands, remotely on your linux server(s) using SSH. By default, most of these commands are only allowed to be run by the root user. The output of systemctl, initctl and service commands depends on whether they are executed via sudo. Furthermore, this ZenPack expects these commands be in the user's path. Normally this is only true for the root user.

Assuming that you've created a user named zenmonitor on your linux servers for monitoring purposes, you can follow these steps to allow the zenmonitor user to run the commands.

  1. Install the sudo package on your server

  2. Allow the zenmonitor user to run the commands via ssh without a TTY

    • Edit /etc/sudoers.d/zenoss (Or /etc/sudoers if sudoers.d not supported) and add the following lines to the bottom of the file:

      Defaults:zenmonitor !requiretty
      Cmnd_Alias ZENOSS_LVM_CMDS = /sbin/pvs, /sbin/vgs, /sbin/lvs, \
          /usr/sbin/pvs, /usr/sbin/vgs, /usr/sbin/lvs
      Cmnd_Alias ZENOSS_SVC_CMDS = /bin/systemctl list-units *, \
          /bin/systemctl status *, /sbin/initctl list, /sbin/service --status-all, \
          /usr/sbin/dmidecode
      zenmonitor ALL=(ALL) NOPASSWD: ZENOSS_LVM_CMDS, ZENOSS_SVC_CMDS

    • Save, ensuring all paths for these commands are correct

Note

  • In order for Ssh operation works correctly, ensure OpenSSH is updated to your distro's current version. This is especially true for older versions of RHEL, CentOS, Ubuntu, and Suse Linux.
  • For Suse Linux the paths for (pvs, vgs, lvs) are located at /sbin/pvs, /sbin/vgs, and /sbin/lvs respectively. Please ensure that each command can be manually executed remotely.
NameDescription
zCommandUsernameLinux user with privileges to gather performance information.
zCommandPasswordPassword for the Linux user.

Table: Linux Configuration Properties

Note

zSshConcurrentSessions property by default equals to 5. In case of increasing this value user has change sshd daemon configuration on target device by increasing allowed session number and restart sshd daemon.

Add a Linux Server

The following procedure assumes that credentials have been set.

  1. Select Infrastructure from the navigation bar.

  2. Select Add a Single Device from the Add Device list of options. The Add a Single Device dialog appears.

  3. Enter the following information in the dialog:

    NameDescription
    Name or IPLinux host to model.
    Device Class/Server/SSH/Linux
    Model DeviceSelect this option unless adding a device with a user name and password different than found in the device class. If you do not select this option, then you must add the credentials (see) and then manually model the device.

    Table: Adding Linux Device Details

  4. Click Add.

Alternatively you can use zenbatchload to add Linux servers from the command line. To do this, you must create a text file with hostname, username and password of all the servers you want to add. Multiple endpoints can be added under the same /Devices/Server/Linux section. Here is an example...

/Devices/Server/Linux
LinuxDevice zCommandUsername="user", zCommandPassword="password"

You can then load the Linux servers into Zenoss Core or Resource Manager as devices with the following command.

zenbatchload <filename>

Installed Items

Installing this ZenPack will add the following items to your Zenoss system.

Device Classes

  • /Server/SSH/Linux

Modeler Plugins

  • zenoss.cmd.uname
  • zenoss.cmd.linux.df
  • zenoss.cmd.linux.alt_kernel_name
  • zenoss.cmd.linux.cpuinfo
  • zenoss.cmd.linux.interfaces
  • zenoss.cmd.linux.lvm
  • zenoss.cmd.linux.memory
  • zenoss.cmd.linux.netstat_an
  • zenoss.cmd.linux.netstat_rn
  • zenoss.cmd.linux.process
  • zenoss.cmd.linux.rpm
  • zenoss.cmd.linux.sudo_dmidecode
  • zenoss.cmd.linux.os_release
  • zenoss.cmd.linux.os_service

Monitoring Templates

  • Device (in /Devices/Server/SSH/Linux)
  • HardDisk (in /Devices/Server/SSH/Linux)
  • IpService (in /Devices)
  • FileSystem (in /Devices/Server/SSH/Linux)
  • ethernetCsmacd (in /Devices/Server/SSH/Linux)
  • SnapshotVolume (in /Devices/Server/SSH/Linux)
  • PhysicalVolume (in /Devices/Server/SSH/Linux)
  • VolumeGroup (in /Devices/Server/SSH/Linux)
  • LogicalVolume (in /Devices/Server/SSH/Linux)
  • OSProcess (in /Devices/Server/SSH/Linux)

Monitoring Templates

Device (in /Devices/Server/SSH/Linux)

  • Data Points
    • ssCpuIdlePerCpu
    • ssCpuUserPerCpu
    • ssCpuSystemPerCpu
    • ssCpuWaitPerCpu
    • sysUpTime
    • laLoadInt15
    • laLoadInt5
    • laLoadInt1
    • Buffers
    • Cached
    • MemFree
    • MemTotal
    • SwapFree
    • SwapTotal
    • ssIORawReceived
    • ssIORawSent
  • Thresholds
    • None
  • Graphs
    • CPU Utilization
    • Load Average
    • Memory Utilization
    • Memory Usage
    • IO Throughput

HardDisk (in /Devices/Server/SSH/Linux)

  • Data Points
    • readsCompleted
    • readsMerged
    • sectorsRead
    • msReading
    • writesCompleted
    • writesMerged
    • sectorsWritten
    • msWriting
    • ioInProgress
    • msDoingIO
    • msDoingIOWeighted
  • Thresholds
    • None
  • Graphs
    • Operation Throughtput
    • Merge Rate
    • Sector Throughtput
    • IO Operation in Progress
    • IO Utilization
    • Weighted IO Utilization

Note

There were significant changes between 2.4 and 2.6 in the I/O subsystem. As a result, some statistic information disappeared. The translation from a disk address relative to a partition to the disk address relative to the host disk happens much earlier. All merges and timings now happen at the disk level rather than at both the disk and partition level as in 2.4. There are only *four* fields available for partitions on 2.6 machines and in this case few datapoints will be missed.

IpService (in /Devices)

  • Data Points
    • None
  • Thresholds
    • None
  • Graphs
    • None

FileSystem (in /Devices/Server/SSH/Linux)

  • Data Points
    • usedBlocks
    • percentInodesUsed
    • totalInodes
    • usedInodes
    • availableInodes
  • Thresholds
    • 90 percent used
  • Graphs
    • Utilization
    • Usage
    • Inode Utilization
    • Inode Usage

ethernetCsmacd (in /Devices/Server/SSH/Linux)

  • Data Points
    • ifInOctets
    • ifOutOctets
    • ifInPackets
    • ifOutPackets
    • ifInErrors
    • ifInDropped
    • ifInOverruns
    • ifOutErrors
    • ifOutCarrier
    • ifOutCollisions
    • ifOutDropped
  • Thresholds
    • 75 percent utilization
  • Graphs
    • Data Throughput
    • Packet Throughput
    • Error Rate

SnaphotVolume (in /Devices/Server/SSH/Linux)

  • Data Points
    • state
    • health
  • Thresholds
    • None
  • Graphs
    • None

PhysicalVolume (in /Devices/Server/SSH/Linux)

  • Data Points
    • size
    • free
    • allocatable
    • exported
    • missing
  • Thresholds
    • unallocatable
    • exported
    • missing
  • Graphs
    • Utilization

VolumeGroup (in /Devices/Server/SSH/Linux)

  • Data Points
    • size
    • free
    • partial
  • Thresholds
    • partial
  • Graphs
    • Utilization

LogicalVolume (in /Devices/Server/SSH/Linux)

  • Data Points
    • state
    • health
  • Thresholds
    • None
  • Graphs
    • None

OSProcess (in /Devices/Server/SSH/Linux)

  • Data Points
    • count
    • cpu
    • mem
  • Thresholds
    • count
  • Graphs
    • Process Count
    • CPU Utilization
    • Memory Usage

Service Impact

When combined with the Zenoss Service Dynamics product, this ZenPack adds built-in service impact capability for services running on Linux. The following service impact relationships are automatically added. These will be included in any services that contain one or more of the explicitly mentioned entities.

Service Impact Relationships

  • HardDisk, IpInterface, IpService, OSProcess, CPU, OSService are impacted by LinuxDevice;
  • PhysicalVolume is impacted by HardDisk;
  • VolumeGroup is impacted by PhysicalVolume;
  • LogicalVolume is impacted by VolumeGroup or HardDisk;
  • SnapshotVolume is impacted by LogicalVolume or HardDisk;
  • FileSystem is impacted by SnapshotVolume or LogicalVolume or HardDisk or LinuxDevice

Daemons

TypeName
Modelerzenmodeler
Performance Collectorzencommand

Supported Distributions

The following Linux distributions are officially supported. Other distributions may also be supported, especially derivatives of Debian and Red Hat Enterprise Linux.

Linux FlavorVersionReleasedEnd of Support
Ubuntu16.04 LTSApril 2016April 2021
15.10October 2015July 2016
15.04April 2015February 2016
14.04 LTSApril 2014April 2019
12.04 LTSApril 2012April 2017
Debian8July 2017April 2020
RedHat Enterprise Linux7June 2014June 2020
6November 2010November 2020
5March 2007March 2017
CentOS7July 2014June 2024
6July 2011November 2020
5April 2007March 2017
SUSE Linux Enterprise Server12October 2014October 2027
11March 2009March 2022

Changes

2.2.6

  • Fix issue with links between Linux and NetApp FileSystem components. (ZPS-1736)
  • Prevent the creation of orphaned processes when an NFS mount becomes unavailable. (ZPS-1499)
  • Document support for RHEL 7, Ubuntu 16.04 LTS, and Debian 8. (ZPS-1820)
  • Fix spurious warnings in zencommand log when monitoring NFS mounted filesystems. (ZPS-1823)
  • Calculate memory utilization using "MemAvailable" when possible. (ZPS-1144)
  • Fix 0.0% utilization in Windows filesystem threshold event summaries. (ZPS-1844)

2.2.5

  • Fix modeler 'AttributeError: type' error when zInterfaceMapIgnoreTypes is set. (ZPS-1695)
  • Fix RPN errors in aliases for memory, swap, and LVM (ZPS-757)

2.2.4

  • Escape the commandTemplate expression for disk and idisk datasources to avoid TALES errors. (ZPS-1616)

2.2.3

  • Use FileSystem_NFS_Client template for all NFS mounts (including nfs4). (ZPS-1495)
  • Fix "IndexError" when modeling tun interfaces. (ZPS-971)
  • Add percentUsed datapoint for filesystems. Use for UI and events. (ZPS-1545)

2.2.2

  • Fix query service overloading during Analytics ETL of Linux devices. (ZPS-1312)
  • Honor zFileSystemIgnoreTypes in zenoss.cmd.linux.df modeler plugin. (ZPS-1494)

2.2.1

  • Improved OS Model parser for os_release modeler plugin. (ZPS-1177)

2.2.0

  • Add disk id modeling for correlation with underlying hardware. (ZPS-510)
  • Add link to underlying hardware from disk details if possible. (ZPS-939)
  • Handle root filesystem reservation more like "df" command. (ZPS-1266)
  • Fix NFS filesystem monitoring not working as expected. (ZPS-1006)

2.1.3

  • Properly account for reserved space to match df output. (ZPS-26739)

2.1.2

  • Improve OS process detection. (ZPS-659)
  • Quiet modeler error messages for missing services. (ZPS-644)

2.1.1

  • Fix "ifconfig" is checked before "ip" Linux Monitor (ZEN-25425)

2.1.0

  • Add cpu_ssCpuUsedPerCpu and mem_MemUsedPercent datapoints. (ZEN-22978)
  • Add common datapoint aliases. (ZEN-24619)
  • Improve ability to model network interface speeds.
  • Improve support for NFS filesystem impact. (ZEN-24478)
  • Improve NFS filesystem linking to NFS server. (ZEN-24478)
  • Disable monitor of NFS mounted filesystems by default. (ZEN-24650)
  • Prevent threshold violations on interfaces with unknown speed.
  • Fix IndexError when modeling older LVM versions. (ZEN-25792)
  • Fix setIdForRelationship error when modeling some LVM versions. (ZEN-22409)

2.0.6

  • Fix "string index out of range" error when modeling older LVM versions (ZEN-25792)

2.0.4

  • Fix "unimplemented" SSH error on 4.2.5 SP709. (ZEN-23392)

2.0.3

  • Fix migration of Linux devices to new type. (ZEN-24293)

2.0.2

  • Added property to ignore unmounted hard disks
  • Improve 1.x to 2.x migration time. (ZEN-24024)

2.0.1

  • Fix invalid event class in filesystem threshold

2.0.0

  • Added support for LVM Physical Volumes, Volume Groups, and Logical Volumes
  • Added support for OpenStack-LVM Integration
  • Added disk (block device) monitoring.
  • Added service monitoring (sysvinit, systemd, upstart).
  • Combined EnterpriseLinux and LinuxMonitor capabilities.
  • Enhanced Impact Support
  • Added Dynamic View Support
  • Completely replaces EnterpriseLinux ZenPack
  • Many other smaller improvements.
Open Source

This ZenPack is developed and supported by Zenoss Inc. Contact Zenoss to request more information regarding this or any other ZenPacks. Click here to view all available Zenoss Open Source ZenPacks.
